As a unique producer of steel fibres producing machines in Serbia, we can proudly say, that our machines are currently working using one of the best producing technologies at the world.
The operational process of our machines are the most lucrative, with lowest production costs and producing capacity of even more than 4000 kilograms of steel fibers per hour.
Producing costs on our machines are very small, almost insignificant comparing with other machines that belongs to other producing companies (calculating: workers needed for working on machine, sacks or carton boxes for packing, electricity, machine wearing, and also maintenance of machine). All those costs goes from cca.30 to 40 Eur per ton. Of course, producing material is excluded from mentioned amount.
On our machines, one man produces and packs fibres, electricity consumption is very small, producing process is automated (automatically speed adjustment during the producing process), only one – two times per year some parts need to be oiled, whereas blades need to be sharpened on 500 – 1000 of produced tons.
On machines competing to ours, we saw till now, some parts need to be oiled on each hour, what is making the producing time longer. For example, if machine has 50 lubricators (places need to be oiled) there are already 50 parts to be oiled. The conclusion is that, on our machines, producing capacity per day is bigger, you do not loose much time while oiling so many parts.
Machine parts used on our machines, are cheap and rarely need to be changed. In case some parts need to be replaced, they could be found in our company any time.
Our machines have one year warranty, followed with machine service and technical support in a period of over 20 years.
Types of machines
for steel fibre production that we are producing
Type 1
- wire diameter: 0,8mm – 1,2mm
- length of fibres 50mm
Machine uses wire from 15 spools ;the speed wire goes into machine is 6,53m in a second.
Electricity consumption is 11 – 12 KW
Type 2
- Diameter of the wire: 0,7mm – 1,1mm
- Length of fibres 60mm
Machine uses wire from 15 spools; the speed wire goes into machine is 6,53m in a second.
Electricity consumption is 11 – 12 KW
Type 3
- Diameter of the wire: 0,55mm – 0,8mm
- Length of fibres 30mm
- Diameter of the wire: 0,40mm – 1,3mm
- Length of fibres 10mm – 70mm
Machine uses wire from 24 spools; the speed wire goes into machine is 8,36m in a second. Electricity consumption is 11 – 12 KW This machine also has the possibility to append tools for serrated fibres production. Serrated fibres that could be produced on machine are made of 0,40mm – 1,3mm wire diameters, with length from 10mm – 70mm. The conclusion is that the machine is able to produce two different forms of fibres, from any diameter, and with each possible length.
„two in one machine"
- Diameter of the wire cord 0,15mm / till wire 0,4mm
- Length of fibres from 3mm – 30mm
Machine uses wire from 12 spools working with steel cord /micro fibres;
- from 40 spools working with wire/straight fibres.
- The speed wire goes into machine is 8,36m/s
- Diameter of the wire 0,40mm
- Length of fibres from 6mm – 30mm
Machine uses wire from 12 spools; the speed wire goes into machine is 8,36m/s
We can offer you
|
Machines for steel fibres production - OPEN type
|
Machines for steel fibres production - CLOSED type
|
|

|

|
| Same specifications. |
|
